1 AWG 1 Cores H07ZZ-F Bare Copper Halogen-Free Heavy-Duty Flexible Cable 4880101
Allowable Ampacity for 1 AWG 1 Cores H07ZZ-F Bare Copper Halogen-Free Heavy-Duty Flexible Cable 4880101: 100 Amps
Also Known as:
Mueller Cable, Flexible Earthing Cable, Bare Copper Cable, Flexible Control Cable, H07ZZ-F Cable, 4880101
Description:
H07ZZ-F is a harmonized, halogen-free, heavy-duty, flexible, black jacketed multi conductor 750V. European cable. Recommended when halogen-free, low-smoke and corrosive gas properties are required in case of fire. Designed for use in electrical equipment under medium mechanical stress in dry and damp interiors. H07ZZ-F cables are used in equipment in industry works such as boilers, heating plates, hand lamps, electric tools (drills, circular saws) and transportable motors or machines at site. Also recommended for stage technology applications. Not suitable for continuous outdoor use
Construction:
• Fine bare copper strands
• Strands to VDE-0295 Class-5, IEC 60228 Cl-5
• Halogen-free cross-linked rubber insulation
• Color code VDE-0293-308
• Halogen-free cross-linked rubber outer jacket
• Low smoke and corrosive gas
• UV resistant
Technical:
• Flexing voltage: 450/750 volts
• Fixed voltage: 600/1000 volts
• Test voltage: 2500 volts
• Flexing bending radius: 10.0 x Ø
• Fixed bending radius: 4.0 x Ø
• Flexing Temp: -5º C to +70º C
• Fixed Temp: -20º C to +70º C
• Flame retardant: IEC 60332.3
• Insulation resistance: 20 MΩ x km
Approvals:
• <HAR> HD22.13 S1 & A1
• VDE-0282 Part-13
• CE low voltage directive 73/23/EEC & 93/68/EEC.
• IEC 60245-4
• ROHS compliant
Specification:
• Size AWG: 1
• Number of Stranded: 400/26
• Number of Cores: 1
• Nominal OD: 0.650 - 0.811” Inch
• CU Weight : 225 LBS/MFT
• Weight 1000ft: 750 LBS/MFT
• Part Number: 4880101
